43 inch outdoor android wifi network digital charging plie kiosk for bus gas station display machine

FOB Reference Price:Get Latest Price
$2,500.00 - $5,000.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Weiwen
Model Number:
WW-SNT-43172
Type:
TFT, outdoor waterproof lcd display
Application:
Indoor
Viewing Angle:
170/160(H/V)
Pixel Pitch:
88/88/88/89
Color:
16.7M
Contrast Ratio:
4000:1
Brightness:
2000cd/m*2
Response Time:
6.5MS
Input Voltage:
AC 110V~240V, 50/60HZ
color:
white/ black
WIFI:
YES
Main board:
H61
Certificate:
ROHS,C-Tick ,CE,FCC
IP 65:
YES
Year estalished:
2007
waterproof:
yes
Max Resolution:
1980*1080
Panel Size:
930.24*523.26MM
Supply Ability
Supply Ability:
1000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Inner 4CM PE foam,Middle export carton box,Outer export wooden box
Port
shenzhen
Lead Time :
7-25 days(according to quantity)

43 inch outdoor android wifi network digital charging plie kiosk for bus gas station display machine





PC Parameter



 Mainboard

H81

 CPU

INTER Dual Core 2GHz

 HDD

1x2.5" COM interface 250GB(optional 160GB, 500GB)

 DDR

1x2GB DDR2 SO-DIMM 800Hz (optional 1GB)

 Video

Intel Graphics Media Accelerator (945G)

 Input interface

2x USB 2.0, 1xRJ45EMAC (optional AVI/TV/HDMI)



Touch Screen Parameter

 Transmittance

 ≥92%, 100% max (without Glass)

 Outline Dimension

 988(W±2.0)X581(D± 2.0)X8mm(H± 0.5)

 Detection Form

 Infrared rays interception detection form

 Active Area

 930mm(W)x523mm(D)

 Resolution

 4096(W)x4096(D)

 Output Format

 Coordinate Output

 Optical Element Pace

 5.97mm

 Minimum Touch body Diameter

 >5mm

 Response Speed

 16ms—25ms

 Touch Accuracy

 ±1.5mm





 Electricity

 Scan Frequency

 50Hz

 USB1.1

 Connector type

 A type

 Transmission speed

 12Mbps

 Signal

 +5V, D-, D+, GND

 Connector

 USB A Port connector for cable

 Temperature Range

 Operating -40°C~70°C

 Storage -40°C ~80°C

 Humidity

 Operating 0%-85%, non condensing

 Storage 0%-95%, non condensing

 Power Supply

 DC 5V ± 5%, 270mA~290mA

 Communication Interface

 USB Port or RS232 (Plug & Play, No Drive)

 Communication Distance

 25Meter





Software:

 Operation System

 Windows XP.7.8/Vista

 Scanning Mode

 Auto Start, Always Scanning

 Movement Mode

 Input Point, Finishing Point, Following, Continuous Detection





Benefits:
• Vandal proof, wear-resistant
• Maintenance free, longer life expectancy
• Fault tolerance design to ensure reliability
• Versatile touch object
• Super transparency
• Integrated controller
• Operable in various light conditions, indoor and outdoor























Typical Applications:

• POS
• ATM
• Desktop touch monitor
• Ticket machine
• In-vehicles and transportation
• Medical instrument
• Industrial control systems
